Custom Gradient Types

gradiente is not limited to built-in CSS gradients. You can register your own gradient type and make it work with the same public API:

parse(...)
isGradient(...)
format(...)
transformTo(...)
transformFrom(...)

This is what makes gradiente extensible.

Core idea

A gradient type is not just a string format.

In gradiente, a gradient type is a class that knows how to:

• read ABI data
• create a gradient instance
• expose structured properties
• serialize itself back to string
• work with transformers

Mental model

gradient string
  ↓
parseStringToAbi()
  ↓
GradientFactory
  ↓
registered gradient class
  ↓
gradient object

Example:

const gradient = parse('linear-gradient(to right, red, blue)')

Internally:

linear-gradient(...)
  ↓
ABI with functionName = "linear-gradient"
  ↓
GradientFactory.get("linear-gradient")
  ↓
LinearGradient.fromAbi(...)
  ↓
LinearGradient instance

GradientFactory

GradientFactory is the registry that connects a gradient function name to a gradient class.

GradientFactory.add("linear-gradient", LinearGradient)
GradientFactory.add("radial-gradient", RadialGradient)
GradientFactory.add("conic-gradient", ConicGradient)

When parse() receives a string, gradiente uses this registry to find the correct class.

Required static interface

A custom gradient class must implement the static gradient interface:

export interface IGradientStatic<TGradient extends GradientBase = GradientBase> {
  fromAbi(abi: GradientAbi): TGradient
  fromString(input: string): TGradient
}

This means every registered gradient class must know how to create itself from:

• ABI
• string input

Instance interface

A gradient instance should behave like every other gradient:

export interface IGradientBase<TConfig = unknown> {
  readonly type: GradientType
  readonly isRepeating: boolean
  readonly config: TConfig
  readonly stops: GradientStop[]

  clone(): this
  toString(): string
  toJSON(): GradientData<TConfig>
  addStop(stop: GradientStop): void
  removeStop(index: number): void
  equals(other: IGradientBase<TConfig>): boolean
}

This is important.

Once your custom gradient follows this shape, it can participate in the same ecosystem as built-in gradients.

What registration does

Registration teaches gradiente how to create a gradient.

GradientFactory.add("my-gradient", MyGradient)

After this, the factory can resolve:

parse("my-gradient(...)")

Without registration, gradiente does not know what class should handle the input.

Basic custom gradient structure

A custom gradient usually looks like this:

import {
  GradientBase,
  type GradientAbi,
  type GradientStop,
} from 'gradiente'

type MyGradientConfig = {
  angle: number
}

export class MyGradient extends GradientBase<MyGradientConfig> {
  public readonly type = 'my-gradient'
  public readonly isRepeating = false

  public static fromString(input: string): MyGradient {
    return this.fromAbi(parseStringToAbi(input))
  }

  public static fromAbi(abi: GradientAbi): MyGradient {
    return new MyGradient({
      config: {
        angle: 0,
      },
      stops: [
        // convert ABI inputs into stops
      ],
    })
  }

  public clone(): this {
    return new MyGradient({
      config: { ...this.config },
      stops: [...this.stops],
    }) as this
  }

  public toString(): string {
    return `my-gradient(...)`
  }
}

This is only a simplified example.

The real implementation should parse config, stops, positions, hints, and validation rules according to your gradient type.

Full lifecycle

A custom gradient type usually goes through this lifecycle:

1. define the gradient syntax
2. define the ABI pattern
3. implement the gradient class
4. register it in GradientFactory
5. optionally add transformers
6. use it through public API

Step 1 - define the syntax

First decide what your gradient looks like.

Example:

my-gradient(45deg, red, blue)

This means the function name is:

my-gradient

The input contains:

config, color-stop, color-stop

Step 2 - define validation rules

Use the Pattern DSL to describe allowed ABI structure.

^[config,color-stop,color-stop].

This means:

begin pattern
config
then color-stop
then color-stop
end pattern

For a more flexible type:

^[([config,color-stop]|color-stop),~color-stop].

This allows:

config, color-stop
config, color-stop, color-stop
color-stop
color-stop, color-stop

The pattern controls what structures are accepted before the gradient class is created.

Step 3 - implement fromAbi

fromAbi() is the most important part.

It receives parsed ABI data and converts it into your gradient class.

public static fromAbi(abi: GradientAbi): MyGradient {
  if (abi.functionName !== 'my-gradient') {
    throw new Error('Expected my-gradient')
  }

  return new MyGradient({
    config: parseMyConfig(abi.inputs),
    stops: parseMyStops(abi.inputs),
  })
}

This is where your gradient becomes structured.

Step 4 - implement fromString

Usually fromString() is a small helper:

public static fromString(input: string): MyGradient {
  return this.fromAbi(parseStringToAbi(input))
}

The string is parsed into ABI first.

Then ABI is converted into a class instance.

Step 5 - implement serialization

Your gradient should be able to return back to string:

gradient.toString()

Example:

public toString(): string {
  const stops = this.stops.map((stop) => stop.value).join(', ')
  return `my-gradient(${stops})`
}

This is what makes format() work.

format('my-gradient(red, blue)')

Internally:

parse(input).toString()

Step 6 - register the gradient

Register your class:

GradientFactory.add('my-gradient', MyGradient)

Now it becomes available through the public API:

const gradient = parse('my-gradient(red, blue)')

And validation works too:

isGradient('my-gradient(red, blue)') // true

Step 7 - add transformers

A gradient class defines the data model.

A transformer defines how to export it.

GradientFactory.add(...)
  → teaches gradiente how to create the gradient

GradientTransformer.add(...)
  → teaches gradiente how to convert the gradient

Example:

class MyGradientToCss {
  target = 'css'
  gradientType = 'my-gradient'

  to(input: GradientBase<any>): string {
    return input.toString()
  }
}

Register it:

GradientTransformer.add(new MyGradientToCss())

Use it:

transformTo('css', 'my-gradient(red, blue)')

Why this is not just a parser

A parser only answers:

Can I read this string?

A custom gradient type answers more:

Can I parse it?
Can I validate it?
Can I normalize it?
Can I clone it?
Can I serialize it?
Can I transform it?
Can I plug it into another renderer?

That is the difference.

Built-in gradients use the same idea

Built-in gradients are not special.

They are registered gradient classes too:

GradientFactory.add("linear-gradient", LinearGradient)
GradientFactory.add("radial-gradient", RadialGradient)
GradientFactory.add("conic-gradient", ConicGradient)

This means custom gradients can follow the same architecture as internal gradients.

Practical use cases

Custom gradient types are useful when you need:

• mesh gradients
• diamond gradients
• editor-specific gradients
• shader gradients
• design-tool-only gradients
• engine-specific gradient formats

Example: diamond gradient

A future custom gradient could look like:

diamond-gradient(at center, red, blue)

Possible ABI structure:

config, color-stop, color-stop

Pattern:

^[config,color-stop,color-stop].

Registered as:

GradientFactory.add('diamond-gradient', DiamondGradient)

Then exported through:

GradientTransformer.add(new DiamondGradientToCanvas())
GradientTransformer.add(new DiamondGradientToCss())

Summary

Custom gradient support is built around two registries:

GradientFactory
GradientTransformer

Use GradientFactory when you want to teach gradiente how to create a gradient.

Use GradientTransformer when you want to teach gradiente how to export or import it.

Final model

custom gradient syntax
  ↓
ABI
  ↓
custom gradient class
  ↓
GradientFactory registration
  ↓
public API
  ↓
optional transformers
