Inputs and groups

Explore each control in turn: numbers, HEX, color, groups, and files. Each section contains its own example, integration for all five environments, API, and styling variant. The final inspector combines them to edit one object.

Install with npm i @flowscape-ui/dsk and register with a browser-side import '@flowscape-ui/dsk'. For SSR, follow the installation recipes.

Standalone fields and groups

dsk-input, dsk-input-hex, dsk-input-color, and dsk-input-upload need no child content. dsk-input-group is a container for other fields.

In ordinary HTML, custom elements require closing tags, even when empty: <dsk-input></dsk-input>. They are not void elements like native <input>. Writing <dsk-input /> does not close it in HTML and can incorrectly nest subsequent markup.

React JSX and Vue SFC compilers support self-closing <dsk-input /> syntax. These examples use paired tags so the markup also works in ordinary HTML.

dsk-input

Change the object width: type expressions, drag the handle, change the step, or enable readonly.

Add an input

Once DSK is loaded, this HTML is enough:

html

<dsk-input value="120" aria-label="Width"></dsk-input>

You can type a value, drag the handle, and use the arrow keys immediately. No initialization function, state, or event handler is needed. The component includes its own styles.

To limit the value and display a unit, add attributes:

html

<dsk-input
  value="120"
  min="40"
  max="200"
  step="1"
  tag="px"
  aria-label="Width"
></dsk-input>

This starts at 120, allows values from 40 to 200, changes by 1 when dragging or using arrow keys, and displays px beside the value.

Connect it to your project

Install once:

npm i @flowscape-ui/dsk

Choose your environment below. These examples assume an existing client-rendered app with a bundler such as Vite. DSK needs JavaScript to register its custom elements, but you do not need to write JavaScript to make an input work. Import the package once, then use the tag wherever you need it.

html

<!-- index.html in a Vite project -->
<dsk-input value="120" aria-label="Width"></dsk-input>

<script type="module">
  import '@flowscape-ui/dsk';
</script>

tsx

// src/App.tsx
import '@flowscape-ui/dsk';

export default function App() {
  return <dsk-input value="120" aria-label="Width"></dsk-input>;
}

vue

<!-- src/App.vue -->
<script setup lang="ts">
import '@flowscape-ui/dsk';
</script>

<template>
  <dsk-input value="120" aria-label="Width"></dsk-input>
</template>

svelte

<!-- src/App.svelte -->
<script lang="ts">
  import '@flowscape-ui/dsk';
</script>

<dsk-input value="120" aria-label="Width"></dsk-input>

// src/app/app.ts
import '@flowscape-ui/dsk';
import { Component, CUSTOM_ELEMENTS_SCHEMA } from '@angular/core';

@Component({
  selector: 'app-root',
  standalone: true,
  schemas: [CUSTOM_ELEMENTS_SCHEMA],
  template: '<dsk-input value="120" aria-label="Width"></dsk-input>',
})
export class App {}

React with TypeScript and Vue need a one-time configuration, shown below. Vanilla, Svelte, and the Angular example above need no additional custom-element configuration.

React + TypeScript: allow DSK input tags in JSX

Create src/dsk.d.ts. This only teaches TypeScript about the tags; it adds no runtime code. The declaration below covers the attributes used in the examples on this page. Add it once, even if you use several different inputs.

import type { DetailedHTMLProps, HTMLAttributes } from 'react';
import type {
  DskInput,
  DskInputHex,
  DskInputColor,
  DskInputGroup,
  DskInputUpload,
} from '@flowscape-ui/dsk';

type FieldProps<T> = DetailedHTMLProps<HTMLAttributes<T>, T> & {
  value?: string | number;
  min?: string | number;
  max?: string | number;
  step?: string | number;
  tag?: string;
};

declare module 'react' {
  namespace JSX {
    interface IntrinsicElements {
      'dsk-input': FieldProps<DskInput>;
      'dsk-input-hex': FieldProps<DskInputHex> & { hex?: string | number };
      'dsk-input-color': FieldProps<DskInputColor> & {
        format?: string | number;
        'alpha-mode'?: 'hex' | 'percent';
      };
      'dsk-input-group': DetailedHTMLProps<
        HTMLAttributes<DskInputGroup>,
        DskInputGroup
      > & {
        linked?: string;
        'has-mixed-values'?: string;
        'mixed-label'?: string;
      };
      'dsk-input-upload': DetailedHTMLProps<
        HTMLAttributes<DskInputUpload>,
        DskInputUpload
      > & {
        accept?: string;
        placeholder?: string;
        disabled?: boolean;
      };
    }
  }
}

Vue + Vite: recognize dsk-* tags as custom elements

In your existing vite.config.ts, add isCustomElement to the Vue plugin options. Keep your other project settings.

import { defineConfig } from 'vite';
import vue from '@vitejs/plugin-vue';

export default defineConfig({
  plugins: [
    vue({
      template: {
        compilerOptions: {
          isCustomElement: (tag) => tag.startsWith('dsk-'),
        },
      },
    }),
  ],
});

For Next.js, Nuxt, SvelteKit, or another server-rendered app, use the SSR installation examples to load DSK in the browser. The input markup stays the same.

Optional: read the value

Add an event listener only when your application needs to react to an edit. For example, start with the same field:

html

<dsk-input value="120" aria-label="Width"></dsk-input>

Then listen for a confirmed value in your browser entry file:

// src/main.ts, loaded by <script type="module" src="/src/main.ts"></script>
import '@flowscape-ui/dsk';

const field = document.querySelector('dsk-input');
field?.addEventListener('change', () => {
  console.log(field.value); // The current value, e.g. "140".
});

change fires when the user commits an edit. Use input for live updates while typing or dragging. The canvas above is a demonstration of listening to these events; you do not need its code or any demo files to use the input itself.

API and behavior

This table applies to dsk-input, dsk-input-hex, and dsk-input-color. Groups and uploads have separate APIs below. Global HTML attributes (id, class, style, title) remain available.

Attribute	Property	Default	Behavior
`value`	`value`	`""`	Current value; empty displays the placeholder.
`min / max`	`min / max`	`""`	Optional bounds; omitted decimal bounds are unbounded.
`step`	`step`	`"" → 1`	Positive drag and fallback keyboard increment.
`key-horizontal-step`	`keyHorizontalStep`	`"" → step`	Left / Right increment.
`key-vertical-step`	`keyVerticalStep`	`"" → step`	Down / Up increment.
`placeholder`	`placeholder`	`""`	Hint for an empty field.
`src`	`src`	`""`	Handle image URL; broken images fall back to the default icon.
`progression`	`progression`	`linear`	linear, exponential, logarithmic drag response.
`positioning`	`positioning`	`center`	left, center, right text and placeholder alignment.
`tag`	`tag`	`""`	Display-only suffix or prefix; not part of the value.
`tag-position`	`tagPosition`	`right`	left or right position for the tag.
`tag-gap`	`tagGap`	`4px`	CSS column gap; nonnegative bare numbers mean pixels.
`select-on-focus`	`selectOnFocus`	`false`	Select all when focus first enters.
`loopafter`	`loopAfter`	`false`	Wrap at both bounds during drag and keyboard edits.
`loopafter-min`	`loopAfterMin`	`false`	Wrap below min to max.
`loopafter-max`	`loopAfterMax`	`false`	Wrap above max to min.
`disabled`	`disabled`	`false`	Prevent interaction and disable form submission.
`readonly`	`readOnly`	`false`	Keep focus and reading, prevent edits.
`name`	`name`	`""`	Name for native form submission.
`aria-label`	`ariaLabel`	`Numeric value / Hexadecimal value / Color value`	Accessible name forwarded to the internal field.

disabled and readonly use presence semantics: even disabled="false" disables the field. select-on-focus and the three loopafter* flags accept the literal string "false"; removing them also disables the behavior. Wrapping requires two finite bounds with max > min, preserves overshoot, and does not apply to manual entry or .value assignments. Enabled loopafter turns on both directions regardless of the individual flags.

The tag never changes the value or submitted data. Invalid positioning falls back to center, tag-position to right, and an invalid CSS gap to 4px. Numeric value, bound, and step setters accept numbers, strings, null, or undefined; empty values clear the field and nullish bound/step assignments remove their attributes.

value reads as a string. valueAsNumber reads a number or NaN for empty/invalid drafts and accepts numeric assignments. focus(options?), blur(), and select() control the internal field. Do not parse unfinished expressions into your model.

html

<dsk-input
  value="160"
  min="0"
  max="360"
  step="1"
  key-horizontal-step="1"
  key-vertical-step="10"
  tag="px"
  tag-position="right"
  tag-gap="6px"
  positioning="right"
  select-on-focus
  loopafter
  aria-label="Width"
></dsk-input>

Interaction

Use positioning="left", positioning="center", or positioning="right" to align the value and placeholder within the text field. The default is center; missing, empty, or unsupported attribute values also use center. Update it at runtime through the attribute or the typed field.positioning property (InputPositioning). The handle stays on the left, and changing alignment does not modify the value or emit input events. CSS through ::part(input) can still override the alignment.

html

<dsk-input value="40" positioning="right" aria-label="Width"></dsk-input>

The component contains a drag handle on the left and an editable numeric field on the right. Drag the handle right to increase the value and left to decrease it. Pointer dragging supports mouse, pen, and touch.

Mouse dragging uses Pointer Lock with a visible virtual resize cursor that wraps across viewport edges. Values change only in response to mouse movement; holding still never changes the value. Release commits and restores the native cursor at its original lock position; Escape, focus loss, or interruption cancels the drag. The browser cannot move the native cursor to the virtual cursor position. If Pointer Lock is unavailable or denied, ordinary dragging remains available with screen limits and no automatic changes. Touch and pen use ordinary dragging. Numeric min/max bounds still apply.

You can also type directly into the field. Enter or focus loss commits the value and clamps it to the bounds. Incomplete text is allowed while editing; an invalid draft restores the last committed value. Manually entered values are not rounded to a step grid.

Keyboard adjustments apply only while the internal text field is focused. Clicking or tabbing into it activates them; Escape removes focus, so subsequent arrow keys no longer adjust that field.

Key	Action
Arrow Right / Arrow Left	Increase / decrease by `key-horizontal-step`, falling back to `step`.
Arrow Up / Arrow Down	Increase / decrease by `key-vertical-step`, falling back to `step`.
Page Up / Page Down	Increase / decrease by ten ordinary `step` increments.
Enter	Commit the current draft.
Escape	Cancel the draft or active drag, restore its previous value, and remove focus.

Home and End retain their usual text editing behavior. Arrow keys combined with Shift, Alt, Ctrl, or Meta also keep native editing behavior; they do not adjust the number. Disabled and readonly fields cannot be adjusted, and Escape can still remove focus from a readonly field. Each numeric keyboard adjustment respects bounds and emits input followed by change only when the value changes.

The progression controls drag distance, not the allowed value range:

linear changes the value at a constant rate.
exponential makes larger drags change the value faster.
logarithmic makes larger drags change the value more slowly.

All three modes support zero and negative values. Dragging starts from the value at pointer-down and uses whole increments of step. In linear mode, each four horizontal pixels correspond to one increment.

Reaching min or max resets the drag reference to that bound. Further outward movement is discarded, so reversing direction immediately begins accumulating steps away from the bound. Escape still restores the original value from pointer-down.

Expressions, selection, and history

Manual entry accepts +, -, *, /, parentheses, unary signs, decimal numbers, and scientific notation. Enter or blur evaluates the expression and clamps its result to the bounds: (20 + 5) * 2 becomes 50. Invalid expressions and division by zero restore the last committed value. Expressions are parsed without executing JavaScript. While editing, value contains the draft; valueAsNumber remains NaN for expression text until it is committed. Programmatic value assignments still accept numeric values, not expressions. Arrow-key adjustment evaluates a valid draft before applying the step.

Enable select-on-focus or select-on-focus="true" to select the whole value when focus enters the field. It defaults to false and supports the boolean selectOnFocus property. Later clicks while focused place the caret normally; select-on-focus="false" disables automatic selection.

html

<dsk-input value="40" select-on-focus aria-label="Value"></dsk-input>

While focused, use Ctrl+Z to undo and Ctrl+Shift+Z to redo (Cmd on macOS). These shortcuts use the physical KeyZ key, so they work independently of the active keyboard layout. Each field keeps its own history of up to 100 committed states. A confirmed text edit, keyboard increment, or completed drag is one history step. Undo during an uncommitted edit restores the committed value; redo restores that draft. A new edit after undo clears the redo branch. Restoring committed values emits input and change; restoring a draft emits only input. Disabled and readonly fields cannot change through history shortcuts. Programmatic value assignments, form resets, and changes to min/max/step establish a new history baseline. Escape cancels the current draft or drag without adding a history entry.

Events and forms

Numeric, HEX, and color fields emit bubbling, composed input and change events without a custom detail. During input, the value may be an incomplete draft. Use committed change for document history and validate values for live previews. Groups forward their children's events; upload also emits dsk-upload-reject.

The three editable value types participate in native forms through ElementInternals in supported browsers. name sets the key, disabled excludes the value, and form.reset() restores the initial value. Empty fields submit an empty string. Groups submit no separate value; upload files must be appended manually. Attributes such as required, pattern, type, and multiple do not add native input validation to these custom elements.

html

<form id="inspector-form">
  <dsk-input name="width" value="160" min="0" aria-label="Width"></dsk-input>
  <dsk-input-color
    name="fill"
    value="FF007A"
    aria-label="Fill"
  ></dsk-input-color>
  <button type="reset">Reset</button>
</form>

const form = document.querySelector<HTMLFormElement>('#inspector-form')!;
console.log(new FormData(form).get('width')); // "160"

CSS and an alternative appearance

css

/* Add class="custom-input" to the field. */
dsk-input.custom-input {
  --dsk-input-width: 100%;
  --dsk-input-height: 38px;
  --dsk-input-background: #1a181a;
  --dsk-input-color: #f5f5f5;
  --dsk-input-border: 1px solid #606066;
  --dsk-input-border-radius: 0px;
  --dsk-input-focus-color: #ff0073;
}
dsk-input.custom-input::part(input) {
  font-family: ui-monospace, monospace;
  font-weight: 700;
}

Add class="custom-input" to the tag and place the CSS above in your stylesheet. In React use className="custom-input". The same CSS works in every framework; in Vue use a regular, unscoped <style> block for this example.

html

<dsk-input class="custom-input" value="120" aria-label="Width"></dsk-input>

CSS variable	Default
`--dsk-input-width`	`214px`
`--dsk-input-height`	`30px`
`--dsk-input-background`	`#f5f6f8`
`--dsk-input-color`	`#151922`
`--dsk-input-border`	`1px solid #a6afbf`
`--dsk-input-border-radius`	`8px`
`--dsk-input-focus-color`	`#557be8`
`--dsk-input-handle-width`	`30px`

::part(...): container, handle, input, tag.

Set font on the host for typography. --dsk-input-font-size applies to upload only. Replace handle images using src; there is no arbitrary icon slot. Keep focus visible.

dsk-input-hex

Change the HEX format and preview the fill. A single channel becomes grayscale; RGB/RGBA becomes color. Narrowing the format may clear values that cannot be converted exactly.

Add the component

Once DSK is loaded, this HTML is enough:

html

<dsk-input-hex value="557BE8" aria-label="HEX value"></dsk-input-hex>

You can type HEX values, drag the handle, and use the arrow keys immediately. No initialization function, state, or event handler is needed. The component includes its own styles.

To choose the number of HEX digits, add hex:

html

<dsk-input-hex hex="8" value="557BE880" aria-label="HEX value"></dsk-input-hex>

This uses 8 HEX digits for red, green, blue, and alpha. The value contains no leading #.

Connect it to your project

Install once:

npm i @flowscape-ui/dsk

html

<!-- index.html in a Vite project -->
<dsk-input-hex value="557BE8" aria-label="HEX value"></dsk-input-hex>

<script type="module">
  import '@flowscape-ui/dsk';
</script>

tsx

// src/App.tsx
import '@flowscape-ui/dsk';

export default function App() {
  return <dsk-input-hex value="557BE8" aria-label="HEX value"></dsk-input-hex>;
}

vue

<!-- src/App.vue -->
<script setup lang="ts">
import '@flowscape-ui/dsk';
</script>

<template>
  <dsk-input-hex value="557BE8" aria-label="HEX value"></dsk-input-hex>
</template>

svelte

<!-- src/App.svelte -->
<script lang="ts">
  import '@flowscape-ui/dsk';
</script>

<dsk-input-hex value="557BE8" aria-label="HEX value"></dsk-input-hex>

// src/app/app.ts
import '@flowscape-ui/dsk';
import { Component, CUSTOM_ELEMENTS_SCHEMA } from '@angular/core';

@Component({
  selector: 'app-root',
  standalone: true,
  schemas: [CUSTOM_ELEMENTS_SCHEMA],
  template: `
    <dsk-input-hex value="557BE8" aria-label="HEX value"></dsk-input-hex>
  `,
})
export class App {}

Use the one-time React TypeScript and Vue configuration from the first example. You do not need to repeat it for each input.

For Next.js, Nuxt, SvelteKit, or another server-rendered app, use the SSR installation examples to load DSK in the browser. The input markup stays the same.

Optional: read the value

Add an event listener only when your application needs to react to an edit. For example, start with the same field:

html

<dsk-input-hex value="557BE8" aria-label="HEX value"></dsk-input-hex>

Then listen for a confirmed value in your browser entry file:

// src/main.ts, loaded by <script type="module" src="/src/main.ts"></script>
import '@flowscape-ui/dsk';

const field = document.querySelector('dsk-input-hex');
field?.addEventListener('change', () => {
  console.log(field.value);
});

API and behavior

Inherits the shared dsk-input attributes, properties, and methods. Differences are listed below.

<dsk-input-hex> inherits the same handle dragging, keyboard adjustment, progression, selection, history, looping, tags, alignment, forms, events, and styling API. Its default handle is a hash SVG; use src to replace it with an image. The handle does not add a # to the field value.

html

<dsk-input-hex
  hex="6"
  value="FE0000"
  step="1"
  select-on-focus
  aria-label="Color channels"
></dsk-input-hex>

The hex attribute selects the format; the default is 6. The typed hex property reads a HexFormat number and accepts a supported number, its string form, or null/undefined to remove the attribute:

`hex`	Channel layout	Full range
`1`	One channel, one HEX digit	`0`–`F`
`2`	One channel, two HEX digits	`00`–`FF`
`3`	RGB, one HEX digit per channel	`000`–`FFF`
`6`	RGB, two HEX digits per channel	`000000`–`FFFFFF`
`8`	RGBA, two HEX digits per channel	`00000000`–`FFFFFFFF`

Literal input accepts an optional leading #, is normalized to uppercase, and is padded on the left to the selected width. A value longer than the selected format is invalid. For example, #ab becomes 0000AB in format 6. A complete literal such as 1e3 is HEX (0001E3 in format 6), not scientific notation. The value and submitted form value omit the leading #.

Channel order and bounds

Drag and keyboard adjustment fill channels in order: red, green, blue, then alpha. A completed channel stays at its maximum while the next channel increases. Decreasing drains channels in reverse order. Step sizes count channel units rather than changes to the numeric rank:

text

FE0000 + 1 → FF0000
FF0000 + 1 → FF0100
FF0100 - 1 → FF0000
FFFFFF00 + 1 → FFFFFF01   (RGBA)

valueAsNumber retains a positional channel rank with red as the least significant channel. In format 6, FF0000 has rank 255 and 000100 has rank 256. This representation is used for bounds and arithmetic expressions; drag and keyboard steps use sequential channel filling instead.

min and max are HEX strings interpreted in the selected format and ordered by the same channel rank. Missing bounds use the format's full range. For example, min="FE0000" max="010100" spans ranks 254 through 257 in format 6. The usual clamp and loop flags operate on that range. Manual entry and programmatic value updates clamp; looping applies to drag and keyboard adjustment.

step, key-horizontal-step, and key-vertical-step use positive decimal safe integers. Fractional, zero, negative, unsafe, or invalid steps use their fallback: step defaults to 1, and each keyboard step defaults to the effective step.

HEX expressions

Manual expressions support the same safe arithmetic operators as the numeric input. Operands are decimal unless prefixed with 0x or #; explicit HEX operands are decoded using the configured channel order. The result must be a whole-number rank.

text

0xFF0000 + 1 → 000100
#FF0000 + 1  → 000100
255 + 1      → 000100

A complete HEX literal is recognized before expression evaluation. Add an operator when you intend arithmetic. Programmatic .value assignments accept literals; expressions are evaluated during user editing. Expression arithmetic changes the numeric rank, not the channel-filling position used by dragging and arrow keys.

Changing formats

Changing hex converts the current value by channels:

Format 3 to 6 expands each nibble by multiplying it by 17: F80 becomes FF8800.
Format 6 to 8 adds opaque alpha: FF8800 becomes FF8800FF.
Format 8 to 6 discards alpha.
Converting bytes to nibbles is allowed only when every retained byte is a multiple of 17. Otherwise the value becomes empty, avoiding silent rounding.
A single channel becomes red, with green and blue set to zero and alpha opaque when present. A color converted to one channel keeps red.

Form reset restores the initial value converted from its original format into the currently selected format. The same exact-conversion rules apply, including clearing a value that cannot narrow without rounding.

The playground includes a separate HEX example with format, value, bounds, step, image, loop, and select-on-focus controls, plus its own HTML and event readouts.

CSS and an alternative appearance

css

/* Add class="custom-input" to the field. */
dsk-input-hex.custom-input {
  --dsk-input-width: 100%;
  --dsk-input-height: 38px;
  --dsk-input-background: #1a181a;
  --dsk-input-color: #f5f5f5;
  --dsk-input-border: 1px solid #606066;
  --dsk-input-border-radius: 0px;
  --dsk-input-focus-color: #ff0073;
}
dsk-input-hex.custom-input::part(input) {
  font-family: ui-monospace, monospace;
  font-weight: 700;
}

html

<dsk-input-hex
  class="custom-input"
  value="557BE8"
  aria-label="HEX value"
></dsk-input-hex>

CSS variable	Default
`--dsk-input-width`	`214px`
`--dsk-input-height`	`30px`
`--dsk-input-background`	`#f5f6f8`
`--dsk-input-color`	`#151922`
`--dsk-input-border`	`1px solid #a6afbf`
`--dsk-input-border-radius`	`8px`
`--dsk-input-focus-color`	`#557be8`
`--dsk-input-handle-width`	`30px`

::part(...): container, handle, input, tag.

Set font on the host for typography. --dsk-input-font-size applies to upload only. Replace handle images using src; there is no arbitrary icon slot. Keep focus visible.

dsk-input-color

RGBA updates the object fill. Compare the combined field with percentage alpha mode, and switch between RGB and RGBA.

Add the component

Once DSK is loaded, this HTML is enough:

html

<dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>

You can edit the HEX color, drag the swatch, and adjust opacity immediately. No initialization function, state, or event handler is needed. The component includes its own styles.

To edit transparency as a percentage, add format and alpha-mode:

html

<dsk-input-color
  value="FF007A80"
  format="8"
  alpha-mode="percent"
  aria-label="Fill"
></dsk-input-color>

This displays a color swatch, the HEX color, and a separate opacity percentage. 80 is the alpha byte, approximately 50% opacity.

Connect it to your project

Install once:

npm i @flowscape-ui/dsk

html

<!-- index.html in a Vite project -->
<dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>

<script type="module">
  import '@flowscape-ui/dsk';
</script>

tsx

// src/App.tsx
import '@flowscape-ui/dsk';

export default function App() {
  return <dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>;
}

vue

<!-- src/App.vue -->
<script setup lang="ts">
import '@flowscape-ui/dsk';
</script>

<template>
  <dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>
</template>

svelte

<!-- src/App.svelte -->
<script lang="ts">
  import '@flowscape-ui/dsk';
</script>

<dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>

// src/app/app.ts
import '@flowscape-ui/dsk';
import { Component, CUSTOM_ELEMENTS_SCHEMA } from '@angular/core';

@Component({
  selector: 'app-root',
  standalone: true,
  schemas: [CUSTOM_ELEMENTS_SCHEMA],
  template: `
    <dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>
  `,
})
export class App {}

Use the one-time React TypeScript and Vue configuration from the first example. You do not need to repeat it for each input.

For Next.js, Nuxt, SvelteKit, or another server-rendered app, use the SSR installation examples to load DSK in the browser. The input markup stays the same.

Optional: read the value

Add an event listener only when your application needs to react to an edit. For example, start with the same field:

html

<dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>

Then listen for a confirmed value in your browser entry file:

// src/main.ts, loaded by <script type="module" src="/src/main.ts"></script>
import '@flowscape-ui/dsk';

const field = document.querySelector('dsk-input-color');
field?.addEventListener('change', () => {
  console.log(field.value);
});

API and behavior

Inherits the shared dsk-input attributes, properties, and methods. Differences are listed below.

<dsk-input-color> extends DskInputHex and replaces the default hash handle with a live color swatch. It inherits HEX parsing, sequential channel filling, expressions, integer stepping, bounds, dragging, history, looping, selection, tags, alignment, forms, and events.

html

<dsk-input-color
  format="8"
  value="557BE880"
  step="1"
  aria-label="Fill color"
></dsk-input-color>

Use format="6" for RGB or format="8" for RGBA. The default and unsupported-format fallback are 6; one-channel and three-digit formats are not available on this element. The typed format property reads a ColorFormat number (6 or 8) and accepts either number, its string form, or null/undefined to remove the attribute. The inherited JavaScript hex property maps to the same setting. Color markup uses the canonical format attribute; a hex HTML attribute is ignored.

Changing 6 to 8 appends opaque alpha (557BE8 becomes 557BE8FF). Changing 8 to 6 removes alpha (557BE880 becomes 557BE8). The submitted value is the uppercase HEX string without a leading #; alpha is present only in format 8. Bounds are HEX strings in the chosen format, and steps are positive decimal safe integers, with the same fallback rules as the HEX input.

Alpha editing modes

For format="8", alpha-mode="hex" (default) edits the complete RGBA value in one field. Set alpha-mode="percent" to show a six-digit RGB editor with a separate dsk-input for opacity on the right:

html

<dsk-input-color
  format="8"
  alpha-mode="percent"
  value="557BE880"
></dsk-input-color>

The percent field accepts 0–100 and supports manual entry, expressions, arrows, and dragging its % handle. Its step is one percentage point. RGB edits and the color handle preserve alpha; opacity edits preserve RGB. Both editors share the color input's Undo/Redo history and emit input/change from the color host. The public value, valueAsNumber, and submitted form value keep their RGBA representation. Switching modes preserves the exact alpha byte. Format 6 always shows a single RGB field.

Percentages map to the nearest 8-bit alpha (50% maps to 80). Values loaded from HEX display up to two decimal places (80 displays as 50.2%). The typed alphaMode property accepts 'hex', 'percent', or null/undefined; invalid attributes fall back to HEX mode. Customize the right field with --dsk-input-alpha-width (default 76px) and the alpha, alpha-input, and alpha-handle parts.

Color preview

The handle layers the color over a black-and-white checkerboard SVG. The checkerboard is visible through transparent pixels in RGBA mode. Valid literal drafts update the swatch immediately, including short literals normalized to the selected width. An empty or invalid draft shows the checkerboard alone, so the previous color never lingers. Expression text also shows the checkerboard until the expression is committed.

Set src to replace the swatch with an image. Clearing src restores the live swatch. The default checkerboard is bundled from assets/patterns/checkerboard.svg; consumers do not need to serve a separate asset.

The shared input CSS variables and parts remain available. --dsk-input-swatch-size sets the square's size (default 16px). The additional swatch part is the outer checkerboard square and the color part is its inner SVG rectangle. The rectangle uses SVG fill for its color; a CSS fill override replaces the live preview color.

css

dsk-input-color {
  --dsk-input-swatch-size: 18px;
}

dsk-input-color::part(swatch) {
  border-radius: 3px;
}

The playground has a separate color example with live parameters, opaque/translucent/transparent presets, generated HTML, and event output.

CSS and an alternative appearance

css

/* Add class="custom-input" to the field. */
dsk-input-color.custom-input {
  --dsk-input-width: 100%;
  --dsk-input-height: 38px;
  --dsk-input-background: #1a181a;
  --dsk-input-color: #f5f5f5;
  --dsk-input-border: 1px solid #606066;
  --dsk-input-border-radius: 0px;
  --dsk-input-focus-color: #ff0073;
}
dsk-input-color.custom-input::part(input) {
  font-family: ui-monospace, monospace;
  font-weight: 700;
}

html

<dsk-input-color
  class="custom-input"
  value="FF007A"
  aria-label="Fill"
></dsk-input-color>

CSS variable	Default
`--dsk-input-width`	`214px`
`--dsk-input-height`	`30px`
`--dsk-input-background`	`#f5f6f8`
`--dsk-input-color`	`#151922`
`--dsk-input-border`	`1px solid #a6afbf`
`--dsk-input-border-radius`	`8px`
`--dsk-input-focus-color`	`#557be8`
`--dsk-input-handle-width`	`30px`
`--dsk-input-swatch-size`	`16px`
`--dsk-input-alpha-width`	`76px`

::part(...): container, handle, input, tag, swatch, color, alpha, alpha-input, alpha-handle.

color is an SVG rectangle: overriding fill replaces the live swatch. alpha-input and alpha-handle are exported from the nested field.

Set font on the host for typography. --dsk-input-font-size applies to upload only. Replace handle images using src; there is no arbitrary icon slot. Keep focus visible.

dsk-input-group

Two fields control width and height. linked copies edits; has-mixed-values shows differing values without losing the real dimensions.

Add the component

Once DSK is loaded, this HTML is enough:

html

<dsk-input-group>
  <dsk-input value="120" aria-label="Width"></dsk-input>
  <dsk-input value="80" aria-label="Height"></dsk-input>
</dsk-input-group>

Place fields inside the group. They are arranged together and remain editable immediately. No initialization function, state, or event handler is needed. The component includes its own styles.

To synchronize the fields when the user edits one of them, add linked:

html

<dsk-input-group linked="true">
  <dsk-input-group>
    <dsk-input value="120" aria-label="Width"></dsk-input>
    <dsk-input value="80" aria-label="Height"></dsk-input>
  </dsk-input-group>
  <dsk-input value="80" aria-label="Height"></dsk-input>
</dsk-input-group>

Without linked, the fields are independent. With linked="true", an edit copies the value to the other fields. This does not preserve an aspect ratio.

Connect it to your project

Install once:

npm i @flowscape-ui/dsk

html

<!-- index.html in a Vite project -->
<dsk-input-group>
  <dsk-input value="120" aria-label="Width"></dsk-input>
  <dsk-input value="80" aria-label="Height"></dsk-input>
</dsk-input-group>

<script type="module">
  import '@flowscape-ui/dsk';
</script>

tsx

// src/App.tsx
import '@flowscape-ui/dsk';

export default function App() {
  return (
    <dsk-input-group>
      <dsk-input value="120" aria-label="Width"></dsk-input>
      <dsk-input value="80" aria-label="Height"></dsk-input>
    </dsk-input-group>
  );
}

vue

<!-- src/App.vue -->
<script setup lang="ts">
import '@flowscape-ui/dsk';
</script>

<template>
  <dsk-input-group>
    <dsk-input value="120" aria-label="Width"></dsk-input>
    <dsk-input value="80" aria-label="Height"></dsk-input>
  </dsk-input-group>
</template>

svelte

<!-- src/App.svelte -->
<script lang="ts">
  import '@flowscape-ui/dsk';
</script>

<dsk-input-group>
  <dsk-input value="120" aria-label="Width"></dsk-input>
  <dsk-input value="80" aria-label="Height"></dsk-input>
</dsk-input-group>

// src/app/app.ts
import '@flowscape-ui/dsk';
import { Component, CUSTOM_ELEMENTS_SCHEMA } from '@angular/core';

@Component({
  selector: 'app-root',
  standalone: true,
  schemas: [CUSTOM_ELEMENTS_SCHEMA],
  template: `
    <dsk-input-group>
      <dsk-input value="120" aria-label="Width"></dsk-input>
      <dsk-input value="80" aria-label="Height"></dsk-input>
    </dsk-input-group>
  `,
})
export class App {}

Use the one-time React TypeScript and Vue configuration from the first example. You do not need to repeat it for each input.

For Next.js, Nuxt, SvelteKit, or another server-rendered app, use the SSR installation examples to load DSK in the browser. The input markup stays the same.

Optional: read the value

Add an event listener only when your application needs to react to an edit. For example, start with the same field:

html

<dsk-input-group>
  <dsk-input value="120" aria-label="Width"></dsk-input>
  <dsk-input value="80" aria-label="Height"></dsk-input>
</dsk-input-group>

Then listen for a confirmed value in your browser entry file:

// src/main.ts, loaded by <script type="module" src="/src/main.ts"></script>
import '@flowscape-ui/dsk';

const field = document.querySelector('dsk-input-group');
field?.addEventListener('change', () => {
  console.log(field.values);
});

API and behavior

`dsk-input-group` attribute	Property	Default
`linked`	`linked: boolean`	`false`
`has-mixed-values`	`hasMixedValues: boolean`	`false`
`mixed-label`	`mixedLabel: string`	`Mixed`

linked uses presence semantics; has-mixed-values="false" disables automatic comparison. Set aria-label on the group and label its individual controls.

Property / method	Purpose
`inputs`	Readonly array of fields in DOM order
`values`	Strings or `null` for mixed fields
`storedValues`	Actual strings regardless of mixed presentation
`setMixed(field, mixed = true)`	Set manual mixed presentation
`isMixed(field)`	Read mixed state
`registerInput(field, adapter)`	Register an adapter
`unregisterInput(field)`	Remove an adapter; returns boolean

<dsk-input-group> coordinates existing DSK, native HTML, and custom inputs. Importing the package registers it and exports DskInputGroup and the InputGroupAdapter type.

html

<dsk-input-group id="dimensions" mixed-label="Mixed" aria-label="Dimensions">
  <dsk-input value="120" aria-label="Width"></dsk-input>
  <input type="number" value="80" aria-label="Height" />
</dsk-input-group>

linked is a boolean presence attribute, absent by default. Set group.linked = true or add linked to copy subsequent user edits to every editable field. Remove the attribute or set the property to false to unlink; linked="false" still counts as present. Enabling linking alone does not overwrite existing values. Values are copied directly, without proportional scaling. Use compatible formats and constraints because each control still applies its own validation and normalization. Disabled and readonly fields are skipped, and nested groups remain independent.

const group = document.querySelector('dsk-input-group')!;
const width = document.querySelector('dsk-input')!;
group.linked = true;
group.mixedLabel = 'Multiple values';
group.setMixed(width);
console.log(group.isMixed(width)); // true
console.log(group.values); // [null, "80"]
group.setMixed(width, false); // Restore the saved value and placeholder.

Mixed state belongs to the group in memory, separately for each field. There is no mixed attribute on inputs. The group saves the value and placeholder, clears the value, and writes mixed-label (default Mixed) into the ordinary placeholder. By default, the application chooses mixed fields through setMixed. Typing replaces that state with the new value; a linked edit also clears mixed state on editable peers. Removing mixed without an edit restores the saved value, unless application code has already supplied another value. The label never becomes an input value. Native controls must support placeholders to display the label; use an adapter for controls such as selects or sliders with another presentation.

Enable has-mixed-values="true" (or group.hasMixedValues = true) for automatic focus-based presentation. When actual field values differ, all inactive fields display the mixed placeholder and return null in group.values. Focusing a field by click or keyboard restores its value; the previous field saves its current value and shows the placeholder. With focus outside the fields, all differing fields show placeholders. Equal values remain visible. has-mixed-values="false" or removing the attribute disables this mode and restores values. The default is off; the empty attribute also enables it.

group.storedValues returns the actual values in DOM order, including values temporarily hidden by placeholders. HTML inputs use an empty string for their visible value, not the literal string "null". Linked editing updates stored peer values too; if all values become equal, the automatic mixed presentation clears. Use either automatic mode or explicit per-field setMixed for a given workflow; explicit mixed flags remain independent of the automatic comparison.

Automatic mixed presentation needs only HTML; setMixed is an optional API for applications that explicitly manage individual fields, not a requirement for has-mixed-values:

html

<dsk-input-group has-mixed-values="true" mixed-label="Mixed">
  <dsk-input value="120" aria-label="Width"></dsk-input>
  <input type="number" value="80" aria-label="Height" />
</dsk-input-group>

inputs returns controls in DOM order. values returns strings, with null for mixed fields. The group has an accessible group role; label the group and its individual controls. Child fields retain focus, keyboard handling, and form ownership. Mixed fields have an empty value for form submission; the group does not submit a separate form value.

Listen for bubbling input and change on the group and read group.values. Peer writes are silent, so a user edit produces only the source event. Programmatic .value assignments are also silent and do not synchronize peers. An unchanged change following input does not repeat the synchronization.

Custom elements with a writable string/number .value and bubbling input/change events participate automatically. Events emitted inside Shadow DOM must be composed. For the default mixed presentation, expose a writable .placeholder and accept an empty value. Other control APIs can use an adapter:

const custom = document.querySelector<HTMLElement>('#custom-field')!;
group.registerInput(custom, {
  getValue: (field) => field.dataset.amount ?? '',
  setValue: (field, value) => {
    field.dataset.amount = value;
    field.textContent = value;
  },
  setMixed(field, mixed, label) {
    field.textContent = mixed ? label : this.getValue(field);
  },
});
// The custom field dispatches bubbling input/change after user edits.
// group.unregisterInput(custom) removes the adapter.

Adapter writes should be silent. Optional setMixed owns the custom mixed presentation and preserves its own value; without it, the group uses the default empty value and placeholder behavior. Registered controls must be descendants of this group. Internal controls of a recognized custom element are not counted separately.

Style children normally, use ::part(container) for the group layout, and configure --dsk-input-group-gap (default 8px) or --dsk-input-group-wrap (default nowrap). The group does not impose a link button: bind any application-owned toggle to .linked.

CSS and an alternative appearance

css

/* Add class="custom-input" to the group. */
dsk-input-group.custom-input {
  --dsk-input-group-gap: 12px;
  --dsk-input-group-wrap: wrap;
  --dsk-input-background: #1a181a;
  --dsk-input-color: #f5f5f5;
  --dsk-input-border: 1px solid #606066;
  --dsk-input-border-radius: 0px;
  --dsk-input-height: 38px;
  --dsk-input-focus-color: #ff0073;
}
dsk-input-group.custom-input::part(container) {
  align-items: center;
}
dsk-input-group.custom-input dsk-input::part(input) {
  font-family: ui-monospace, monospace;
  font-weight: 700;
}

html

<dsk-input-group class="custom-input">
  <dsk-input value="120" aria-label="Width"></dsk-input>
  <dsk-input value="80" aria-label="Height"></dsk-input>
</dsk-input-group>

CSS variable	Default
`--dsk-input-group-gap`	`8px`
`--dsk-input-group-wrap`	`nowrap`

::part(...): container.

dsk-input-upload

Choose an image for the object or a PDF/TXT file for its label. Change accept, try a rejected file, and clear the selection.

Add the component

Once DSK is loaded, this HTML is enough:

html

<dsk-input-upload aria-label="File"></dsk-input-upload>

Click to choose a file or drop one onto the field. The filename and preview update automatically. No initialization function, state, or event handler is needed. The component includes its own styles.

To limit the file types, add accept:

html

<dsk-input-upload
  accept="image/*,.pdf,.doc,.docx"
  placeholder="Choose a file"
  aria-label="File"
></dsk-input-upload>

This accepts images, PDF, DOC, and DOCX. The component shows an image thumbnail or a document icon and filename. Selecting a file does not upload it to a server.

Connect it to your project

Install once:

npm i @flowscape-ui/dsk

html

<!-- index.html in a Vite project -->
<dsk-input-upload aria-label="File"></dsk-input-upload>

<script type="module">
  import '@flowscape-ui/dsk';
</script>

tsx

// src/App.tsx
import '@flowscape-ui/dsk';

export default function App() {
  return <dsk-input-upload aria-label="File"></dsk-input-upload>;
}

vue

<!-- src/App.vue -->
<script setup lang="ts">
import '@flowscape-ui/dsk';
</script>

<template>
  <dsk-input-upload aria-label="File"></dsk-input-upload>
</template>

svelte

<!-- src/App.svelte -->
<script lang="ts">
  import '@flowscape-ui/dsk';
</script>

<dsk-input-upload aria-label="File"></dsk-input-upload>

// src/app/app.ts
import '@flowscape-ui/dsk';
import { Component, CUSTOM_ELEMENTS_SCHEMA } from '@angular/core';

@Component({
  selector: 'app-root',
  standalone: true,
  schemas: [CUSTOM_ELEMENTS_SCHEMA],
  template: ` <dsk-input-upload aria-label="File"></dsk-input-upload> `,
})
export class App {}

Use the one-time React TypeScript and Vue configuration from the first example. You do not need to repeat it for each input.

For Next.js, Nuxt, SvelteKit, or another server-rendered app, use the SSR installation examples to load DSK in the browser. The input markup stays the same.

Optional: read the value

Add an event listener only when your application needs to react to an edit. For example, start with the same field:

html

<dsk-input-upload aria-label="File"></dsk-input-upload>

Then listen for a confirmed value in your browser entry file:

// src/main.ts, loaded by <script type="module" src="/src/main.ts"></script>
import '@flowscape-ui/dsk';

const field = document.querySelector('dsk-input-upload');
field?.addEventListener('change', () => {
  console.log(field.file);
});

change fires when a file is selected or cleared. field.file is a File or null; send it to your server only when your application needs to. The canvas above is a demonstration of listening to these events; you do not need its code or any demo files to use the input itself.

API and behavior

`dsk-input-upload` attribute	Property	Default
`accept`	`accept: string`	`""`
`placeholder`	`placeholder: string`	`Choose a file`
`disabled`	`disabled: boolean`	`false`
`aria-label`	`ariaLabel`	`Choose file`
–	`file: File	null`
–	`files: readonly File[]`	`[]`
–	`clear(): void`	–

Group and upload do not inherit the numeric API. For example, min, step, tag, and readonly do not configure upload. files is read-only; assign file instead.

<dsk-input-upload> selects one local file. It does not upload data automatically.

html

<dsk-input-upload
  accept="image/*,.pdf,.doc,.docx"
  placeholder="Choose a file"
  aria-label="Attachment"
></dsk-input-upload>

Click or press Enter/Space to open the native picker, or drop a file onto the field. Images display a thumbnail; documents display a colored extension icon. Unsupported or damaged images fall back to the document icon. Operating-system file icons are not available through the browser File API.

accept: comma-separated extensions (including the leading dot), MIME types, or image/*, audio/*, video/*. Empty accepts all types. Matching is case-insensitive. Both the picker result and dropped files are checked. MIME matching uses File.type; use explicit extensions for formats whose MIME type may be empty.
disabled: boolean attribute/property that prevents user interaction.
placeholder: empty-state text; defaults to Choose a file.
file: selected File or null; assign a File to initialize or replace the selection. The same filter applies to assignments.
files: a fresh read-only array containing zero or one file.
clear(): removes the selection without emitting input/change events.

User selection and removal emit bubbling, composed input and change events. Programmatic assignments are silent. A rejected file leaves the current selection unchanged and emits dsk-upload-reject with { files, accept, reason }; reason is type or multiple. File validation here is for selection UX; applications must validate uploads on their server. Changing accept affects subsequent selections, not the current file.

const upload = document.querySelector('dsk-input-upload')!;
upload.addEventListener('change', () => {
  const file = upload.file;
  if (!file) return;
  const body = new FormData();
  body.append('attachment', file);
  // Send body using your application's upload endpoint.
});

The control is not form-associated: append its file to FormData explicitly. File object URLs are released on replacement, clearing, and disconnection. Preview generation never reads documents as HTML.

Use the shared --dsk-input-width, --dsk-input-height, --dsk-input-background, --dsk-input-color, --dsk-input-border, --dsk-input-border-radius, --dsk-input-focus-color, and --dsk-input-font-size variables. Shadow parts: container, button, icon, filename, clear, status.

CSS and an alternative appearance

css

/* Add class="custom-input" to the field. */
dsk-input-upload.custom-input {
  --dsk-input-width: 100%;
  --dsk-input-height: 38px;
  --dsk-input-background: #1a181a;
  --dsk-input-color: #f5f5f5;
  --dsk-input-border: 1px solid #606066;
  --dsk-input-border-radius: 0px;
  --dsk-input-focus-color: #ff0073;
}
dsk-input-upload.custom-input::part(filename) {
  font-family: ui-monospace, monospace;
  font-weight: 700;
}

html

<dsk-input-upload class="custom-input" aria-label="File"></dsk-input-upload>

CSS variable	Default
`--dsk-input-width`	`214px`
`--dsk-input-height`	`30px`
`--dsk-input-background`	`#f5f6f8`
`--dsk-input-color`	`#151922`
`--dsk-input-border`	`1px solid #a6afbf`
`--dsk-input-border-radius`	`8px`
`--dsk-input-focus-color`	`#557be8`
`--dsk-input-font-size`	`14px`

::part(...): container, button, icon, filename, clear, status.

Individual example source

These optional files implement the documentation canvases and their extra controls. You do not need them to use the inputs. The simple markup above is sufficient. If you reuse the full demo, its returned cleanup function removes listeners and releases image URLs. Load demo modules only in the browser for SSR.

single-input.ts

import '@flowscape-ui/dsk';
import './single-input.css';
import type {
  DskInput,
  DskInputHex,
  DskInputColor,
  DskInputUpload,
} from '@flowscape-ui/dsk';

export type InputExampleKind =
  | 'dsk-input'
  | 'dsk-input-hex'
  | 'dsk-input-color'
  | 'dsk-input-group'
  | 'dsk-input-upload';

/** Each instance owns its controls, preview, and resource cleanup. */
export function mountSingleInput(
  host: HTMLElement,
  kind: InputExampleKind,
  styled = false,
): () => void {
  const root = document.createElement('section');
  root.className = `dsk-single-input${styled ? ' dsk-single-input-custom' : ''}`;
  root.dataset.kind = kind;
  const markup: Record<InputExampleKind, string> = {
    'dsk-input':
      '<dsk-input value="120" min="40" max="200" step="1" tag="px" aria-label="Width"></dsk-input><label>Step <select data-option="step"><option>1</option><option>0.5</option><option>10</option></select></label><label><input type="checkbox" data-option="readonly"> readonly</label>',
    'dsk-input-hex':
      '<dsk-input-hex hex="6" value="557BE8" aria-label="HEX value"></dsk-input-hex><label>hex <select data-option="hex"><option>1</option><option>2</option><option>3</option><option selected>6</option><option>8</option></select></label>',
    'dsk-input-color':
      '<dsk-input-color format="8" value="FF007A80" aria-label="Fill"></dsk-input-color><label>alpha-mode <select data-option="alpha-mode"><option>hex</option><option>percent</option></select></label><label>format <select data-option="format"><option>6</option><option selected>8</option></select></label>',
    'dsk-input-group':
      '<dsk-input-group aria-label="Dimensions"><dsk-input value="120" min="40" max="200" aria-label="Width"></dsk-input><dsk-input value="80" min="40" max="200" aria-label="Height"></dsk-input></dsk-input-group><label><input type="checkbox" data-option="linked"> linked</label><label><input type="checkbox" data-option="has-mixed-values"> has-mixed-values</label>',
    'dsk-input-upload':
      '<dsk-input-upload accept="image/*,.pdf,.txt" aria-label="Asset"></dsk-input-upload><label>accept <select data-option="accept"><option value="image/*,.pdf,.txt">Images, PDF, TXT</option><option value="image/*">Images</option><option value=".pdf,.txt">PDF, TXT</option></select></label><label><input type="checkbox" data-option="disabled"> disabled</label>',
  };
  root.innerHTML = `<div class="dsk-single-input-controls">${markup[kind]}<output aria-live="polite"></output></div><dsk-pan-zoom aria-label="${kind} canvas"><div class="dsk-single-input-object"><img alt="" hidden><span>dsk</span></div></dsk-pan-zoom>`;
  host.append(root);
  const control = root.querySelector(kind)!;
  const object = root.querySelector<HTMLElement>('.dsk-single-input-object')!;
  const image = object.querySelector('img')!;
  const caption = object.querySelector('span')!;
  const output = root.querySelector('output')!;
  const listeners = new AbortController();
  const options = { signal: listeners.signal };
  let url: string | undefined;
  const release = () => {
    if (url) URL.revokeObjectURL(url);
    url = undefined;
    image.removeAttribute('src');
    image.hidden = true;
  };
  const render = () => {
    if (kind === 'dsk-input') {
      const field = control as DskInput;
      if (Number.isFinite(field.valueAsNumber))
        object.style.width = `${field.valueAsNumber}px`;
      output.textContent = `value: ${field.value || '(empty)'}`;
    } else if (kind === 'dsk-input-group') {
      const group = root.querySelector('dsk-input-group')!;
      const [width, height] = group.storedValues;
      if (width && Number.isFinite(Number(width)))
        object.style.width = `${width}px`;
      if (height && Number.isFinite(Number(height)))
        object.style.height = `${height}px`;
      output.textContent = JSON.stringify({
        values: group.values,
        storedValues: group.storedValues,
      });
    } else if (kind === 'dsk-input-hex' || kind === 'dsk-input-color') {
      const field = control as DskInputHex | DskInputColor;
      const value = field.value;
      if (/^[0-9A-F]+$/.test(value) && [1, 2, 3, 6, 8].includes(value.length)) {
        const hex =
          value.length === 1
            ? value.repeat(6)
            : value.length === 2
              ? value.repeat(3)
              : value;
        object.style.backgroundColor = `#${hex}`;
      }
      output.textContent = `value: ${value || '(empty)'}; rank: ${field.valueAsNumber}`;
    } else {
      output.textContent = `file: ${(control as DskInputUpload).file?.name ?? '(empty)'}`;
    }
  };
  root.addEventListener('input', render, options);
  root.addEventListener('change', render, options);
  root
    .querySelectorAll<HTMLInputElement | HTMLSelectElement>('[data-option]')
    .forEach((option) => {
      option.addEventListener(
        'change',
        () => {
          const attribute = option.dataset.option!;
          if (option instanceof HTMLInputElement)
            control.toggleAttribute(attribute, option.checked);
          else control.setAttribute(attribute, option.value);
          render();
        },
        options,
      );
    });
  if (kind === 'dsk-input-upload') {
    control.addEventListener(
      'change',
      () => {
        release();
        const file = (control as DskInputUpload).file;
        caption.textContent = file?.name ?? 'dsk';
        if (file && file.type.startsWith('image/')) {
          url = URL.createObjectURL(file);
          image.src = url;
          image.hidden = false;
        }
        render();
      },
      options,
    );
    control.addEventListener(
      'dsk-upload-reject',
      () => {
        output.textContent = 'File rejected. Check accept; choose one file.';
      },
      options,
    );
    image.addEventListener('error', release, options);
  }
  render();
  return () => {
    listeners.abort();
    release();
    root.remove();
  };
}

single-input.css

css

.dsk-single-input {
  display: grid;
  grid-template-columns: minmax(0, 1fr) minmax(0, 1fr);
  margin: 0;
  color: var(--dsk-example-text, #f5f5f5);
  --dsk-input-width: 100%;
  --dsk-input-background: var(--dsk-example-surface, #1a181a);
  --dsk-input-color: var(--dsk-example-text, #f5f5f5);
  --dsk-input-border: 1px solid var(--dsk-example-divider, #303033);
  --dsk-input-border-radius: 0px;
  --dsk-input-height: 36px;
  --dsk-input-focus-color: var(--dsk-example-accent, #ff0073);
  --dsk-input-group-wrap: wrap;
  --dsk-pan-zoom-grid-color: var(--dsk-example-divider, #303033);
}
.dsk-single-input-controls {
  min-width: 0;
  display: flex;
  flex-direction: column;
  justify-content: center;
  padding: 24px;
  background: var(--dsk-example-surface, #151515);
}
.dsk-single-input label {
  display: flex;
  align-items: center;
  gap: 8px;
  margin: 14px 0 0;
  min-height: 32px;
  justify-content: space-between;
  color: var(--dsk-example-muted, #bcb9bf);
  font-size: 13px;
}
.dsk-single-input label:has(input[type='checkbox']) {
  flex-direction: row-reverse;
}
.dsk-single-input output {
  display: block;
  font:
    12px/1.6 ui-monospace,
    monospace;
  margin-top: 20px;
  padding-top: 16px;
  border-top: 1px solid var(--dsk-example-divider, #303033);
  color: var(--dsk-example-muted, #bcb9bf);
  overflow-wrap: anywhere;
}
.dsk-single-input dsk-pan-zoom {
  height: 100%;
  min-height: 280px;
  border-left: 1px solid var(--dsk-example-divider, #303033);
  overflow: hidden;
  border-radius: 0;
}
.dsk-single-input-object {
  position: absolute;
  left: 0;
  top: 0;
  width: 120px;
  height: 80px;
  transform: translate(-50%, -50%);
  border-radius: 16px;
  background: #ff007a;
  display: grid;
  place-items: center;
  overflow: hidden;
}
.dsk-single-input-object img {
  position: absolute;
  width: 100%;
  height: 100%;
  object-fit: cover;
}
.dsk-single-input-object img[hidden] {
  display: none;
}
.dsk-single-input-object span {
  position: relative;
  color: white;
  font:
    700 20px system-ui,
    sans-serif;
  max-width: 90%;
  overflow: hidden;
  white-space: nowrap;
  text-overflow: ellipsis;
  text-shadow: 0 1px 4px #0008;
}
.dsk-single-input-custom {
  --dsk-input-background: #1a181a;
  --dsk-input-color: #f5f5f5;
  --dsk-input-border: 1px solid #606066;
  --dsk-input-border-radius: 0px;
  --dsk-input-height: 38px;
  --dsk-input-focus-color: #ff0073;
  --dsk-input-handle-width: 38px;
  --dsk-input-group-gap: 12px;
}
.dsk-single-input-custom
  :is(dsk-input, dsk-input-hex, dsk-input-color)::part(input) {
  font-family: ui-monospace, monospace;
  font-weight: 700;
}
.dsk-single-input-custom dsk-input-upload::part(filename) {
  text-align: left;
  font-weight: 700;
}
@media (max-width: 648px) {
  .dsk-single-input {
    grid-template-columns: 1fr;
  }
  .dsk-single-input dsk-pan-zoom {
    height: 230px;
    min-height: 230px;
    border-left: 0;
    border-top: 1px solid var(--dsk-example-divider, #303033);
  }
}

Combined object inspector

All five components work together here. X/Y change position, the group changes dimensions, HEX changes corner radius, RGBA changes fill and opacity, and upload changes the image or label. Model state appears below the canvas; Reset restores the fields and camera.

Start with a small combination

The full inspector above includes all five components. To understand how to connect fields to an object, start with just width, height, and fill. The inputs work on their own; the event handler only updates the preview object.

1. Add the markup. Choose a framework tab. These are client-rendered examples; use the same React TypeScript / Vue setup and SSR guidance as the first input.

html

<!-- index.html; load src/main.ts from the next step -->
<section class="input-preview">
  <dsk-input-group>
    <dsk-input
      data-size="width"
      value="120"
      min="40"
      max="200"
      aria-label="Width"
    ></dsk-input>
    <dsk-input
      data-size="height"
      value="80"
      min="40"
      max="200"
      aria-label="Height"
    ></dsk-input>
  </dsk-input-group>
  <dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>
  <div class="preview-object">dsk</div>
</section>

<script type="module" src="/src/main.ts"></script>

tsx

// src/App.tsx
import '@flowscape-ui/dsk';
import './input-preview.css';
import { updatePreview } from './input-preview';

export default function App() {
  return (
    <section onInput={updatePreview} className="input-preview">
      <dsk-input-group>
        <dsk-input
          data-size="width"
          value="120"
          min="40"
          max="200"
          aria-label="Width"
        ></dsk-input>
        <dsk-input
          data-size="height"
          value="80"
          min="40"
          max="200"
          aria-label="Height"
        ></dsk-input>
      </dsk-input-group>
      <dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>
      <div className="preview-object">dsk</div>
    </section>
  );
}

vue

<!-- src/App.vue -->
<script setup lang="ts">
import '@flowscape-ui/dsk';
import './input-preview.css';
import { updatePreview } from './input-preview';
</script>

<template>
  <section @input="updatePreview" class="input-preview">
    <dsk-input-group>
      <dsk-input
        data-size="width"
        value="120"
        min="40"
        max="200"
        aria-label="Width"
      ></dsk-input>
      <dsk-input
        data-size="height"
        value="80"
        min="40"
        max="200"
        aria-label="Height"
      ></dsk-input>
    </dsk-input-group>
    <dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>
    <div class="preview-object">dsk</div>
  </section>
</template>

svelte

<!-- src/App.svelte -->
<script lang="ts">
  import '@flowscape-ui/dsk';
  import './input-preview.css';
  import { updatePreview } from './input-preview';
</script>

<section oninput={updatePreview} class="input-preview">
  <dsk-input-group>
    <dsk-input data-size="width" value="120" min="40" max="200" aria-label="Width"></dsk-input>
    <dsk-input data-size="height" value="80" min="40" max="200" aria-label="Height"></dsk-input>
  </dsk-input-group>
  <dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>
  <div class="preview-object">dsk</div>
</section>

// src/app/app.ts
import '@flowscape-ui/dsk';
import { Component, CUSTOM_ELEMENTS_SCHEMA } from '@angular/core';
import { updatePreview } from '../input-preview';

@Component({
  selector: 'app-root',
  standalone: true,
  schemas: [CUSTOM_ELEMENTS_SCHEMA],
  styleUrl: '../input-preview.css',
  template: `
    <section (input)="updatePreview($event)" class="input-preview">
      <dsk-input-group>
        <dsk-input
          data-size="width"
          value="120"
          min="40"
          max="200"
          aria-label="Width"
        ></dsk-input>
        <dsk-input
          data-size="height"
          value="80"
          min="40"
          max="200"
          aria-label="Height"
        ></dsk-input>
      </dsk-input-group>
      <dsk-input-color value="FF007A" aria-label="Fill"></dsk-input-color>
      <div class="preview-object">dsk</div>
    </section>
  `,
})
export class App {
  readonly updatePreview = updatePreview;
}

2. Add one small event handler. Create src/input-preview.ts. It reads the fields and updates the object's CSS. Incomplete numeric or color drafts leave the last valid preview unchanged. Every framework above uses this same function.

// src/input-preview.ts
import type { DskInput } from '@flowscape-ui/dsk';

export function updatePreview(event: {
  currentTarget: EventTarget | null;
}): void {
  const root = event.currentTarget;
  if (!(root instanceof HTMLElement)) return;
  const object = root.querySelector<HTMLElement>('.preview-object');
  if (!object) return;

  for (const size of ['width', 'height'] as const) {
    const field = root.querySelector<DskInput>(
      `dsk-input[data-size="${size}"]`,
    );
    if (field && Number.isFinite(field.valueAsNumber)) {
      object.style[size] = `${field.valueAsNumber}px`;
    }
  }
  const fill = root.querySelector('dsk-input-color');
  if (fill && /^[0-9A-F]{6}$/.test(fill.value)) {
    object.style.backgroundColor = `#${fill.value}`;
  }
}

3. Add the styles. Create src/input-preview.css:

css

/* src/input-preview.css */
.input-preview {
  display: grid;
  gap: 16px;
  --dsk-input-group-wrap: wrap;
}
.preview-object {
  display: grid;
  place-items: center;
  width: 120px;
  height: 80px;
  border-radius: 16px;
  background: #ff007a;
  color: white;
}

Vanilla only: connect the listener in src/main.ts. The framework tabs already connect it in their templates.

// src/main.ts (Vanilla only)
import '@flowscape-ui/dsk';
import './input-preview.css';
import { updatePreview } from './input-preview';

document
  .querySelector('.input-preview')
  ?.addEventListener('input', updatePreview);

Optional: full inspector source

The files below power the complete inspector on this page, including pan/zoom, uploads, reset, and the state readout. They are not required for the small example above. If you reuse the full demo, call mountInputLab(host) in the browser after your container mounts, and call the returned cleanup function when that container unmounts. Keep both files together. For Russian labels, use mountInputLab(host, 'ru').

input-lab.ts

import '@flowscape-ui/dsk';
import './input-lab.css';
import type { DskInput, DskPanZoom } from '@flowscape-ui/dsk';

/** Mount a framework-independent inspector and release its resources on teardown. */
export function mountInputLab(
  host: HTMLElement,
  locale: 'en' | 'ru' = 'en',
): () => void {
  const t = (en: string, ru: string) => (locale === 'ru' ? ru : en);
  const root = document.createElement('section');
  root.className = 'dsk-input-lab';
  root.innerHTML = `
    <div class="dsk-input-lab-controls">
      <fieldset><legend>dsk-input</legend>
        <label>X <dsk-input data-field="x" value="0" min="-100" max="100" tag="px" aria-label="X"></dsk-input></label>
        <label>Y <dsk-input data-field="y" value="0" min="-80" max="80" tag="px" aria-label="Y"></dsk-input></label>
      </fieldset>
      <fieldset><legend>dsk-input-group</legend>
        <dsk-input-group aria-label="Dimensions">
          <label>${t('Width', 'Ширина')} <dsk-input data-field="width" value="160" min="40" max="240" tag="px" aria-label="Width"></dsk-input></label>
          <label>${t('Height', 'Высота')} <dsk-input data-field="height" value="120" min="40" max="240" tag="px" aria-label="Height"></dsk-input></label>
        </dsk-input-group>
        <label class="dsk-input-lab-check"><input type="checkbox" data-option="linked"> ${t('Link dimensions', 'Связать размеры')}</label>
        <label class="dsk-input-lab-check"><input type="checkbox" data-option="mixed"> ${t('Show mixed values', 'Показывать разные значения')}</label>
      </fieldset>
      <fieldset><legend>dsk-input-hex</legend>
        <label>${t('Corner radius', 'Скругление')} <dsk-input-hex hex="2" value="18" min="00" max="50" aria-label="Corner radius"></dsk-input-hex></label>
        <small>${t('00–50 HEX = 0–80 px', '00–50 HEX = 0–80 px')}</small>
      </fieldset>
      <fieldset><legend>dsk-input-color</legend>
        <label>${t('Fill', 'Заливка')} <dsk-input-color format="8" alpha-mode="percent" value="FF007AFF" aria-label="Fill"></dsk-input-color></label>
      </fieldset>
      <fieldset><legend>dsk-input-upload</legend>
        <dsk-input-upload accept="image/*,.pdf,.doc,.docx,.txt" aria-label="Object asset"></dsk-input-upload>
        <small>${t('Images fill the object; documents update its label.', 'Изображение заполняет объект, документ меняет подпись.')}</small>
      </fieldset>
      <div class="dsk-input-lab-options">
        <label class="dsk-input-lab-check"><input type="checkbox" data-option="disabled"> disabled</label>
        <label class="dsk-input-lab-check"><input type="checkbox" data-option="readonly"> readonly</label>
        <label>${t('Alignment', 'Выравнивание')} <select data-option="positioning"><option>center</option><option>left</option><option>right</option></select></label>
        <label>${t('Drag response', 'Перетаскивание')} <select data-option="progression"><option>linear</option><option>exponential</option><option>logarithmic</option></select></label>
        <button type="button" data-reset>${t('Reset example', 'Сбросить пример')}</button>
      </div>
    </div>
    <div class="dsk-input-lab-preview">
      <dsk-pan-zoom aria-label="Input example canvas"><div class="dsk-input-lab-object"><img alt=""><span>dsk</span></div></dsk-pan-zoom>
      <div class="dsk-input-lab-toolbar"><span>${t('Pan · scroll to zoom', 'Перетаскивание · прокрутка для зума')}</span><button type="button" data-camera>${t('Center', 'По центру')}</button></div>
      <output class="dsk-input-lab-status" aria-live="polite"></output>
      <pre class="dsk-input-lab-state" aria-label="Object state"></pre>
    </div>`;
  host.append(root);
  const group = root.querySelector('dsk-input-group')!;
  const hex = root.querySelector('dsk-input-hex')!;
  const color = root.querySelector('dsk-input-color')!;
  const upload = root.querySelector('dsk-input-upload')!;
  const canvas = root.querySelector<DskPanZoom>('dsk-pan-zoom')!;
  const object = root.querySelector<HTMLElement>('.dsk-input-lab-object')!;
  const image = object.querySelector('img')!;
  const caption = object.querySelector('span')!;
  const status = root.querySelector('output')!;
  const stateView = root.querySelector('pre')!;
  const inputs = [...root.querySelectorAll<DskInput>('dsk-input')];
  const numeric = [...inputs, hex, color];
  const state = {
    x: 0,
    y: 0,
    width: 160,
    height: 120,
    radius: 24,
    fill: '#FF007AFF',
    file: '',
  };
  const listeners = new AbortController();
  const options = { signal: listeners.signal };
  let imageUrl: string | undefined;
  let commits = 0;
  const releaseImage = () => {
    if (imageUrl) URL.revokeObjectURL(imageUrl);
    imageUrl = undefined;
    image.removeAttribute('src');
    image.hidden = true;
  };
  const render = () => {
    Object.assign(object.style, {
      left: `${state.x}px`,
      top: `${state.y}px`,
      width: `${state.width}px`,
      height: `${state.height}px`,
      borderRadius: `${state.radius}px`,
      backgroundColor: state.fill.slice(0, 7),
      opacity: String(parseInt(state.fill.slice(7, 9), 16) / 255),
    });
    stateView.textContent = JSON.stringify(state, null, 2);
  };
  const sync = () => {
    for (const field of inputs) {
      const key = field.dataset.field;
      if ((key === 'x' || key === 'y') && Number.isFinite(field.valueAsNumber))
        state[key] = field.valueAsNumber;
    }
    const [width, height] = group.storedValues;
    if (width && Number.isFinite(Number(width))) state.width = Number(width);
    if (height && Number.isFinite(Number(height)))
      state.height = Number(height);
    if (/^[0-9A-F]{2}$/.test(hex.value)) state.radius = parseInt(hex.value, 16);
    if (/^[0-9A-F]{8}$/.test(color.value)) state.fill = `#${color.value}`;
    render();
  };
  root.addEventListener('input', sync, options);
  root.addEventListener(
    'change',
    (event) => {
      if (
        !(event.target instanceof HTMLElement) ||
        !event.target.localName.startsWith('dsk-input')
      )
        return;
      sync();
      commits += 1;
      status.textContent = `${t('Committed edits', 'Подтверждённые изменения')}: ${commits}`;
    },
    options,
  );
  upload.addEventListener(
    'change',
    () => {
      releaseImage();
      const file = upload.file;
      state.file = file?.name ?? '';
      caption.textContent = file?.name ?? 'dsk';
      if (
        file &&
        (file.type.startsWith('image/') ||
          /\.(png|jpe?g|webp|gif|svg|avif)$/i.test(file.name))
      ) {
        imageUrl = URL.createObjectURL(file);
        image.src = imageUrl;
        image.hidden = false;
      }
      render();
    },
    options,
  );
  image.addEventListener('error', releaseImage, options);
  upload.addEventListener(
    'dsk-upload-reject',
    () => {
      status.textContent = t(
        'Choose one image, PDF, DOC, DOCX or TXT file.',
        'Выберите одно изображение, PDF, DOC, DOCX или TXT.',
      );
    },
    options,
  );
  root.querySelector('[data-option=linked]')!.addEventListener(
    'change',
    (event) => {
      group.linked = (event.currentTarget as HTMLInputElement).checked;
    },
    options,
  );
  root.querySelector('[data-option=mixed]')!.addEventListener(
    'change',
    (event) => {
      group.hasMixedValues = (event.currentTarget as HTMLInputElement).checked;
    },
    options,
  );
  for (const name of ['disabled', 'readonly', 'positioning', 'progression']) {
    root.querySelector(`[data-option=${name}]`)!.addEventListener(
      'change',
      (event) => {
        const target = event.currentTarget as
          HTMLInputElement | HTMLSelectElement;
        for (const field of numeric) {
          if (target instanceof HTMLInputElement)
            field.toggleAttribute(name, target.checked);
          else field.setAttribute(name, target.value);
        }
        if (name === 'disabled' && target instanceof HTMLInputElement)
          upload.disabled = target.checked;
      },
      options,
    );
  }
  const center = () => {
    canvas.camera = {
      panX: canvas.clientWidth / 2,
      panY: canvas.clientHeight / 2,
      zoom: 1,
    };
  };
  root
    .querySelector('[data-camera]')!
    .addEventListener('click', center, options);
  root.querySelector('[data-reset]')!.addEventListener(
    'click',
    () => {
      group.hasMixedValues = false;
      group.linked = false;
      for (const field of numeric) {
        field.disabled = false;
        field.readOnly = false;
        field.positioning = 'center';
        field.progression = 'linear';
      }
      inputs.forEach((field) => {
        field.value =
          field.dataset.field === 'width'
            ? 160
            : field.dataset.field === 'height'
              ? 120
              : 0;
      });
      hex.value = '18';
      color.value = 'FF007AFF';
      upload.disabled = false;
      upload.clear();
      root
        .querySelectorAll<HTMLInputElement>('input[type=checkbox]')
        .forEach((input) => {
          input.checked = false;
        });
      root.querySelectorAll('select').forEach((select) => {
        select.selectedIndex = 0;
      });
      releaseImage();
      state.file = '';
      caption.textContent = 'dsk';
      commits = 0;
      status.textContent = '';
      sync();
      center();
    },
    options,
  );
  releaseImage();
  render();
  return () => {
    listeners.abort();
    releaseImage();
    root.remove();
  };
}

input-lab.css

css

.dsk-input-lab {
  display: grid;
  grid-template-columns: minmax(0, 1fr) minmax(0, 1.1fr);
  gap: 0;
  background: var(--vp-c-bg, #111111);
  color: #eee;
  font:
    14px/1.5 var(--vp-font-family-base, system-ui),
    sans-serif;
  --dsk-input-width: 100%;
  --dsk-input-border-radius: 0px;
  --dsk-input-height: 36px;
  --dsk-input-background: var(--dsk-example-surface, #1a181a);
  --dsk-input-color: #eee;
  --dsk-input-border: 1px solid var(--dsk-example-divider, #303033);
  --dsk-input-focus-color: #ff007a;
  --dsk-input-group-wrap: wrap;
  --dsk-pan-zoom-grid-color: var(--dsk-example-divider, #303033);
}
.dsk-input-lab-controls {
  min-width: 0;
  padding: 20px;
}
.dsk-input-lab * {
  box-sizing: border-box;
}
.dsk-input-lab fieldset {
  min-width: 0;
  margin: 0 0 12px;
  padding: 10px;
  border: 1px solid var(--dsk-example-divider, #303033);
  border-radius: 0;
}
.dsk-input-lab legend {
  padding: 0 6px;
  color: var(--dsk-example-accent, #ff0073);
  font:
    12px ui-monospace,
    monospace;
}
.dsk-input-lab label {
  display: grid;
  grid-template-columns: 90px minmax(0, 1fr);
  align-items: center;
  gap: 8px;
  margin: 8px 0;
  font-size: 13px;
}
.dsk-input-lab .dsk-input-lab-check {
  display: flex;
}
.dsk-input-lab label > :is(dsk-input, dsk-input-hex, dsk-input-color) {
  flex: 1;
  min-width: 0;
}
.dsk-input-lab dsk-input-group > label {
  width: 100%;
}
.dsk-input-lab small {
  display: block;
  color: var(--dsk-example-muted, #bcb9bf);
  font-size: 12px;
}
.dsk-input-lab button,
.dsk-input-lab select {
  color: #fff;
  background: #111111;
  border: 1px solid var(--dsk-example-divider, #303033);
  border-radius: 0;
  padding: 5px 10px;
  cursor: pointer;
  font: inherit;
}
.dsk-input-lab button:focus-visible,
.dsk-input-lab select:focus-visible {
  outline: 2px solid var(--dsk-example-accent, #ff0073);
  outline-offset: 2px;
}
.dsk-input-lab-options {
  display: flex;
  flex-wrap: wrap;
  gap: 6px 12px;
}
.dsk-input-lab-preview {
  min-width: 0;
  padding: 20px;
  border-left: 1px solid var(--dsk-example-divider, #303033);
  align-self: start;
  position: sticky;
  top: 80px;
}
.dsk-input-lab dsk-pan-zoom {
  height: 320px;
  border: 1px solid var(--dsk-example-divider, #303033);
  border-radius: 0;
  overflow: hidden;
}
.dsk-input-lab-object {
  position: absolute;
  transform: translate(-50%, -50%);
  display: grid;
  place-items: center;
  overflow: hidden;
  box-shadow: 0 20px 45px -20px #ff007a80;
}
.dsk-input-lab-object img {
  position: absolute;
  width: 100%;
  height: 100%;
  object-fit: cover;
}
.dsk-input-lab-object img[hidden] {
  display: none;
}
.dsk-input-lab-object span {
  position: relative;
  max-width: 90%;
  overflow: hidden;
  text-overflow: ellipsis;
  white-space: nowrap;
  color: white;
  font-size: 24px;
  font-weight: 750;
  text-shadow: 0 1px 4px #0008;
}
.dsk-input-lab-toolbar {
  display: flex;
  align-items: center;
  justify-content: space-between;
  gap: 8px;
  padding: 10px 0;
  font-size: 12px;
}
.dsk-input-lab-status {
  display: block;
  min-height: 24px;
  color: var(--dsk-example-muted, #bcb9bf);
}
.dsk-input-lab .dsk-input-lab-state {
  margin: 8px 0 0;
  padding: 12px;
  overflow: auto;
  border-radius: 0;
  background: var(--dsk-example-surface, #151515);
  font:
    12px/1.6 ui-monospace,
    monospace;
}
@media (max-width: 648px) {
  .dsk-input-lab {
    grid-template-columns: 1fr;
    padding: 0;
  }
  .dsk-input-lab-preview {
    position: static;
    grid-row: 1;
    border-left: 0;
    border-bottom: 1px solid var(--dsk-example-divider, #303033);
  }
  .dsk-input-lab dsk-pan-zoom {
    height: 260px;
  }
}

Edit history

Ctrl/Cmd+Z and Ctrl/Cmd+Shift+Z use the shared bounded history store. Linked groups restore all field values together, including different starting values. Unlinked fields keep independent history. Upload controls intentionally have no file history.

Inputs and groups ​

dsk-input ​

Add an input ​

Connect it to your project ​

Optional: read the value ​

API and behavior ​

Interaction ​

Expressions, selection, and history ​

Events and forms ​

CSS and an alternative appearance ​

dsk-input-hex ​

Add the component ​

Connect it to your project ​

Optional: read the value ​

API and behavior ​

Channel order and bounds ​

HEX expressions ​

Changing formats ​

CSS and an alternative appearance ​

dsk-input-color ​

Add the component ​

Connect it to your project ​

Optional: read the value ​

API and behavior ​

Alpha editing modes ​

Color preview ​

CSS and an alternative appearance ​

dsk-input-group ​

Add the component ​

Connect it to your project ​

Optional: read the value ​

API and behavior ​

CSS and an alternative appearance ​

dsk-input-upload ​

Add the component ​

Connect it to your project ​

Optional: read the value ​

API and behavior ​

CSS and an alternative appearance ​

Individual example source ​

Combined object inspector ​

Start with a small combination ​

Optional: full inspector source ​

Edit history ​

Inputs and groups

dsk-input

Add an input

Connect it to your project

Optional: read the value

API and behavior

Interaction

Expressions, selection, and history

Events and forms

CSS and an alternative appearance

dsk-input-hex

Add the component

Connect it to your project

Optional: read the value

API and behavior

Channel order and bounds

HEX expressions

Changing formats

CSS and an alternative appearance

dsk-input-color

Add the component

Connect it to your project

Optional: read the value

API and behavior

Alpha editing modes

Color preview

CSS and an alternative appearance

dsk-input-group

Add the component

Connect it to your project

Optional: read the value

API and behavior

CSS and an alternative appearance

dsk-input-upload

Add the component

Connect it to your project

Optional: read the value

API and behavior

CSS and an alternative appearance

Individual example source

Combined object inspector

Start with a small combination

Optional: full inspector source

Edit history
